TPC 18/4-Basic
Items Include:
Additional side-mounted hand grip
Belt clip
Bit PZ 2
CENTROTEC BH 60 CE Imp magnetic bit holder
FastFix keyless chuck 13mm KC 13-1/2-MMFP
Systainer SYS3 M 187
WH-CE CENTROTEC tool chuck
Additional side-mounted hand grip
Belt clip
Bit PZ 2
CENTROTEC BH 60 CE Imp magnetic bit holder
FastFix keyless chuck 13mm KC 13-1/2-MMFP
Systainer SYS3 M 187
WH-CE CENTROTEC tool chuck
TPC 18/4-Basic-Set
Items Included:
Additional side-mounted hand grip
Belt clip
Bit PZ 2
CENTROTEC BH 60 CE Imp magnetic bit holder
FastFix angle attachment
FastFix keyless chuck 13mm KC 13-1/2-MMFP
BKS SYS3 D6 PZ TX 50 CE Bit cassette
Systainer SYS3 DF M
187
WH-CE CENTROTEC tool chuck
Additional side-mounted hand grip
Belt clip
Bit PZ 2
CENTROTEC BH 60 CE Imp magnetic bit holder
FastFix angle attachment
FastFix keyless chuck 13mm KC 13-1/2-MMFP
BKS SYS3 D6 PZ TX 50 CE Bit cassette
Systainer SYS3 DF M
187
WH-CE CENTROTEC tool chuck
TPC 18/4 5,0/4,0 I-Set
Items Include:
Additional side-mounted hand grip
Belt clip
Bit PZ 2
BKS SYS3 D6 PZ TX 50 CE Bit cassette
BP 18 Li 4.0 HPC-ASI battery pack
BP 18 Li 5.0 ASI battery pack
CENTROTEC BH 60 CE Imp magnetic bit holder
FastFix angle attachment
FastFix keyless chuck 13mm KC 13-1/2-MMFP
Rapid charger TCL 6
Systainer SYS3 DF M
187
WH-CE CENTROTEC tool chuck
Additional side-mounted hand grip
Belt clip
Bit PZ 2
BKS SYS3 D6 PZ TX 50 CE Bit cassette
BP 18 Li 4.0 HPC-ASI battery pack
BP 18 Li 5.0 ASI battery pack
CENTROTEC BH 60 CE Imp magnetic bit holder
FastFix angle attachment
FastFix keyless chuck 13mm KC 13-1/2-MMFP
Rapid charger TCL 6
Systainer SYS3 DF M
187
WH-CE CENTROTEC tool chuck
TPC 18/4 5,0/4,0 I-Set/XL
Items Included:
Additional side-mounted hand grip
Belt clip
Bit PZ 2
BKS SYS3 D6 PZ TX 50 CE Bit cassette
BP 18 Li 4.0 HPC-ASI battery pack
BP 18 Li 5.0 ASI battery pack
CENTROTEC BH 60 CE Imp magnetic bit holder
FastFix angle attachment
FastFix depth stop DC UNI FF
FastFix keyless chuck 13mm KC 13-1/2-MMFP
Rapid charger TCL 6
Systainer SYS3 DF M
187
WH-CE CENTROTEC tool chuck
Additional side-mounted hand grip
Belt clip
Bit PZ 2
BKS SYS3 D6 PZ TX 50 CE Bit cassette
BP 18 Li 4.0 HPC-ASI battery pack
BP 18 Li 5.0 ASI battery pack
CENTROTEC BH 60 CE Imp magnetic bit holder
FastFix angle attachment
FastFix depth stop DC UNI FF
FastFix keyless chuck 13mm KC 13-1/2-MMFP
Rapid charger TCL 6
Systainer SYS3 DF M
187
WH-CE CENTROTEC tool chuck
Functions
Pure Power. Controlled in Four Gears
Powerful. Versatile. With four gears for every application. With the best switching concept you have ever operated. Whether you are working on wood, metal or masonry – thanks to the axial impact feature that can be switched on: The TPC is extremely durable and, thanks to its brushless EC-TEC motor, has extreme resilience and endurance. The large number of attachments, combined with perfectly matched accessories, make the QUADRIVE an unrivalled percussion drill for a wide range of possible uses. What about your hand twisting dangerously if the tool suddenly jams? Our intelligent KickbackStop minimises the risk of this happening. Give it a go: The best drill that Festool has ever built!
- Powerful for work with screws and drills with larger diameters, rapid for clean work progress when working with small diameters
- Maximum performance: Thanks to the extremely powerful, brushless, and therefore long-lasting, EC-TEC motor
- Robust: Resilient four-speed metal gearbox, also fully covered by the comprehensive support provided by Festool Service
- For an even wider range of applications: Axial impact function that can be activated for drilling into masonry
- The QUADRIVE with four gears for every working situation: From screwdriving with 50 Nm torque in first gear to precise drilling at 3600 rpm in fourth gear
- Versatile: Thanks to the FastFix interface, quick conversion without the need for tools for drilling, screwdriving, angular drilling and angular screwdriving
- The depth stop and eccentric adapter also enable depth-limited screwdriving close to edges
- Flexible cordless system: For applications with high power needs, the 4.0 Ah Li-HighPower Compact battery pack provides the ideal powerful, compact and lightweight solution. The 5.0 Ah battery pack is the right choice for even more power for particularly difficult drilling and screwdriving applications. Fully covered: Needless to say, the comprehensive support provided by Festool Service also applies to battery packs
- The high-quality BKS SYS3 D6 PZ TX 50 CE bit cassette is already one of the items included: PZ bit 2 50 mm CE, TX bit 20 50 mm CE, TX bit 25 50 mm CE, TX bit 30 50 mm CE, TX bit 40 50 mm CE, metal drill bit D6 HSS CE
- Mobile: The QUADRIVE comes in a lid compartment Systainer and can be seamlessly integrated into bott vehicle equipment for easy transportation from the bodyshop to the construction site
Product Highlights
- High-speed and durable.The robust four-speed metal gearbox stands out in QUADRIVE with its enormous power and high speeds and it can handle even the greatest of loads. The fully optimised switching concept allows users to switch from any gear straight to any other in a fast and controlled manner. The latest generation of brushless EC-TEC motors enables rapid work progress and clean drilling results.
- Unrivalled range of applications.The large number of attachments, combined with perfectly matched accessories, make the TPC the most versatile percussion drill and it is unrivalled in its class. The smart FastFix interface allows the attachments to be changed quickly and without the need for any tools – for flexible drilling, screwdriving, angular drilling and angular screwdriving. The depth stop and eccentric adapter also enable depth-limited screwdriving close to edges.
- Compact with extra safety.Thanks to its excellent handle ergonomics and short design, the TPC fits perfectly in your hand even when it is bursting with power. To avoid hazards: The electronic KickbackStop minimises the risk of you twisting your wrist if the drill suddenly jams.
Product Details
TPC 18/4-Basic-set
For greater safety when working
The electronic KickbackStop prevents your wrist from twisting dangerously if the drill suddenly becomes caught or jammed, therefore ensuring improved safety when working.
The QUDRADRIVE-four gears, with the right one for every application
1st gear: Demanding tightening of screws up to 10 mm. 2nd gear: Quick screwdriving up to 8 x 300 mm in size. 3rd gear: Powerful drilling with auger bits of up to 20 mm. 4th gear: Quick drilling with medium and small drill bits up to 35 mm, for example Forstner drill bits.
Optimised gear switching
Fast, safe, direct! Switching in any direction – from any gear straight to any other, without intermediate stages. Fixed stops ensure clear engaging. Fast downshifting possible as required.
Increased power in 2nd gear
40% more torque compared to the previous model for full traction with 8 mm screws.
